Why the Revolution
Features & benefits
Quiet enclosed reciprocating air compressors.
- External panels lined with 2 inch foam, plus bottom intake and discharge to cut sound
- Runs with doors on as a fully enclosed package or doors off for extra airflow
- Standard control panel carries an hour meter, ON-OFF switch, power light and fault light
- Oversized bar and plate aftercooler, high temp switch, electronic tank drain and food grade oil
- Mounted refrigerated dryer option saves floor space and installation work
Technical specifications
Models & specs
| Model | Motor power (hp) | Receiver capacity (US gal) | Dimensions L × W × H without dryer (in) | Dimensions L × W × H with dryer (in) |
|---|---|---|---|---|
| BQR5 | 5 | n/a | 61 x 32 x 45 | n/a |
| BQR7F | 7.5 | n/a | 61 x 32 x 45 | n/a |
| BQR10 | 10 | n/a | 68 x 33 x 50 | n/a |
| BQR15F | 15 | n/a | 68 x 33 x 50 | n/a |
| HQR5-8 | 5 | 80 | 70 x 32 x 64 | 71 x 32 x 64 |
| HQR7F | 7.5 | 80 | 70 x 32 x 64 | 71 x 32 x 64 |
| HQR10-12 | 10 | 120 | 76 x 33 x 74 | 93 x 33 x 71 |
| HQR15F-12 | 15 | 120 | 76 x 33 x 74 | 93 x 33 x 71 |
